Allen Bradley MPL-B430P-MJ74AA Servo Motor

Overview

The Allen Bradley MPL-B430P-MJ74AA is a low-inertia AC servo motor designed for high-speed and precise motion control. It belongs to the MP-Series MPL family and provides fast response, accurate positioning, and reliable performance for demanding industrial automation and machine applications.

General Information

Part Number: MPL-B430P-MJ74AA

Manufacturer: Allen-Bradley / Rockwell Automation

Series: MP-Series MPL

Type: Low-Inertia Rotary Servo Motor

Motor Technology: Brushless Permanent-Magnet AC Servo

Frame Size: 115 mm

Rated Speed: 5000 RPM

Rated Torque: 7.1 N·m

Feedback: High-Resolution Absolute Encoder

Brake: With Brake

Brand: Allen-Bradley

Country of Origin: Mexico

Power Specifications

Motor Type: Three-Phase AC Synchronous Servo Motor

Voltage Class: 400/480 V AC

Rated Voltage: 460 V AC

Rated Power: 3.0 kW

Rated Torque: 7.1 N·m

Maximum Speed: 5000 RPM

Duty Rating: S1 Continuous Duty

Communication & Interface

Feedback Device: High-Resolution Absolute Encoder

Feedback Function: Rotor Position and Speed Feedback

Motor Connector: Circular Industrial Connector

Drive Compatibility: Allen-Bradley Motion Control Systems

Interface Function: Motor Power and Feedback Connection for Closed-Loop Servo Control

Environmental

Operating Temperature: 0 to +40 °C

Enclosure Rating: IP66

Cooling Method: Natural Convection

Installation Environment: Industrial Machinery and Protected Control Environments

Dimensions & Weight

Frame Size: 115 mm

Weight: 5.5 kg

New In Stock — Ready for Precision Motion Applications
