Allen Bradley 1746-HSCE2 SLC 500 Multi-Channel High-Speed Counter Module

Overview

The 1746-HSCE2 is a multi-channel high-speed counter module for the Allen Bradley SLC 500 system, designed to capture and process rapid pulses from multiple encoders, sensors, and other field devices simultaneously. It provides precise measurement and timing for complex industrial automation and motion control applications.

General Information

Part Number: 1746-HSCE2

Manufacturer: Allen Bradley

Brand / Country of Origin: Rockwell Automation / USA

Series: SLC 500

Type: Multi-Channel High-Speed Counter Module

Mounting: Panel or rack mounting within SLC 500 chassis

Technology: Multi-channel pulse counting, high-speed signal acquisition, event monitoring

Power Specifications

Supply Voltage: 5 V DC / 24 V DC (backplane powered)

Power Consumption: ≤ 3 W

Input: Powered via SLC 500 backplane

Protection: Reverse-polarity and short-circuit protection

Indicators: LEDs for module status, channel activity, and faults

Communication & Interface

Interface: SLC 500 backplane

Channels: Multiple input channels for simultaneous high-speed pulse counting

Data Rate: High-speed processing for precise motion and process control

Diagnostics: Module and channel fault detection

Operator Interface: Status LEDs for input activity and errors

Reset Features: Supports software or controller-initiated reset

Environmental

Operating Temperature: 0 to 60 °C

Humidity: 5–95% RH, non-condensing

Protection Rating: IP20 (suitable for industrial enclosures)

Vibration / Shock: Complies with industrial-grade standards

Dimensions & Weight

Dimensions (L × W × H): 144.5 × 34.6 × 130.18 mm

Weight: ~ 0.222 kg
