Allen Bradley 1746-OBP8/B SLC 500 Digital DC Output Module

Overview

The Allen Bradley 1746-OBP8/B is a digital DC output module engineered for the SLC 500 PLC platform. It provides dependable sourcing output performance for industrial automation systems, supporting efficient machine control and process automation in demanding industrial environments.

General Information

Part Number: 1746-OBP8/B

Manufacturer: Allen Bradley

Brand: Allen Bradley

Country of Origin: United States

Series: SLC 500

Module Type: Digital DC Output Module

Output Configuration: 8-Point PNP Sourcing Output

Application: Industrial control and automation systems

Installation Method: Rack-mounted within SLC 500 chassis

Status Indicators: Individual LED output indicators

Power Specifications

Output Voltage Range: 10 to 30 V DC

Nominal Output Voltage: 24 V DC

Backplane Current Consumption: Approx. 0.13 A at 5 V DC

Maximum Current per Output: 1 A

Maximum Module Current: 8 A

Isolation Voltage: 1500 V AC

Protection Features: Electronic overload and short-circuit protection

Communication & Interface

Compatible Controllers: Allen Bradley SLC 500 PLC systems

Output Channels: 8 digital DC outputs

Connection Type: Removable terminal block interface

Signal Type: PNP sourcing outputs

Diagnostic Functions: LED channel status monitoring

Switching Speed: Fast response for industrial automation tasks

Environmental

Operating Temperature: 0 to +60 °C

Storage Temperature: −40 to +85 °C

Humidity: 5% to 95% RH, non-condensing

Environmental Rating: Suitable for industrial cabinet installation

Vibration Resistance: Industrial-grade construction

Dimensions & Weight

Dimensions (H × W × D): 144.5 × 34.6 × 130.18 mm

Weight: 0.45 kg
