Allen Bradley 1746-OG16 SLC 500 Digital Output Module

Overview

The Allen Bradley 1746-OG16 is a digital output module designed for the SLC 500 PLC platform. It delivers reliable output switching performance for industrial automation systems, making it suitable for machinery control, production equipment, and process automation applications.

General Information

Part Number: 1746-OG16

Manufacturer: Allen Bradley

Brand: Allen Bradley

Country of Origin: United States

Series: SLC 500

Module Type: Digital Output Module

Output Configuration: 16-Point Digital Output

Application: Industrial automation and discrete output control

Mounting Method: Rack-mounted installation for SLC 500 chassis

Status Indicators: Individual LED output status indicators

Power Specifications

Backplane Current Consumption: Approx. 0.25 A at 5 V DC

Output Voltage Range: 5 to 265 V DC

Maximum Current per Output: 0.25 A

Maximum Module Current: 4 A

Isolation Voltage: 1500 V AC

Protection Features: Built-in output isolation and overload protection

Communication & Interface

Compatible Platform: Allen Bradley SLC 500 PLC systems

Output Channels: 16 digital outputs

Connection Type: Removable terminal block

Signal Type: Digital output interface

Diagnostic Features: LED channel status indication

Switching Performance: Fast response for industrial control operations

Environmental

Operating Temperature: 0 to +60 °C

Storage Temperature: −40 to +85 °C

Humidity: 5% to 95% RH, non-condensing

Protection Rating: Suitable for industrial control cabinet environments

Vibration Resistance: Designed for demanding industrial conditions

Dimensions & Weight

Dimensions (H × W × D): 144.5 × 34.6 × 130.18 mm

Weight: 0.231 kg
