Allen Bradley 1756-OA16 ControlLogix Digital Output Module

Overview

The Allen Bradley 1756-OA16 is a ControlLogix digital output module designed for reliable switching of AC output signals in industrial automation systems. It provides high-density output control for actuators, relays, and field devices, ensuring stable and precise signal execution in demanding control environments.

General Information

Part Number: 1756-OA16

Manufacturer: Allen Bradley

Brand / Country of Origin: Allen Bradley / USA

Series: ControlLogix

Type: Digital Output Module

Mounting: Chassis-mounted within a ControlLogix rack

Technology: High-density AC digital output switching

Application: Industrial automation, machine control, process control, and discrete output systems

Power Specifications

Supply Voltage: Powered via ControlLogix chassis backplane

Output Voltage: AC output (industrial control applications)

Power Consumption: Typical module-level consumption

Isolation: Channel-to-backplane electrical isolation

Protection Features: Surge protection and industrial noise immunity

Status Indicators: LED indicators for channel status and module health

Communication & Interface

Output Channels: 16-point digital output

Signal Type: AC switching output

Load Support: Compatible with industrial actuators, solenoids, and relays

Diagnostics: Channel fault detection and module status reporting

Controller Integration: Fully compatible with ControlLogix processors

Environmental

Operating Temperature: 0°C to +60°C

Storage Temperature: −40°C to +85°C

Humidity: 5% to 95% RH, non-condensing

Environmental Protection: Suitable for industrial cabinet installation

Shock Resistance: Designed for industrial environments

Vibration Resistance: Compliant with standard industrial vibration requirements

Dimensions & Weight

Dimensions (L × W × H): 144.57 × 22 × 105.42 mm

Weight: 0.45 kg
