Allen Bradley 1756-OA16I ControlLogix AC Digital Output Module

Overview

The Allen Bradley 1756-OA16I is a ControlLogix AC digital output module designed for reliable control of industrial field devices. It provides isolated output channels for switching AC loads such as relays, solenoids, and actuators, ensuring stable performance in automation and process control systems.

General Information

Part Number: 1756-OA16I

Manufacturer: Allen Bradley

Brand / Country of Origin: Allen Bradley / USA

Series: ControlLogix

Type: AC Digital Output Module

Mounting: Chassis-mounted within a ControlLogix rack

Technology: Isolated AC digital output switching

Application: Industrial automation, machine control, process systems, and discrete output applications

Power Specifications

Supply Voltage: Powered via ControlLogix chassis backplane

Output Voltage: AC output for industrial switching applications

Power Consumption: Low module-level consumption

Isolation: Channel-to-channel and channel-to-backplane isolation

Protection Features: Surge protection and industrial electrical noise immunity

Status Indicators: LED indicators for channel status and module health

Communication & Interface

Output Channels: 16-point digital output

Signal Type: AC switching output with isolation

Load Support: Compatible with industrial relays, solenoids, and actuators

Diagnostics: Per-channel fault detection and module diagnostics

Controller Integration: Seamless integration with ControlLogix processors

Environmental

Operating Temperature: 0°C to +60°C

Storage Temperature: −40°C to +85°C

Humidity: 5% to 95% RH, non-condensing

Environmental Protection: Suitable for industrial control cabinet installation

Shock Resistance: Designed for industrial environments

Vibration Resistance: Compliant with industrial vibration standards

Dimensions & Weight

Dimensions (L × W × H): 144.57 × 22 × 105.42 mm

Weight: 0.259 kg

Fast Delivery!
