Allen Bradley 1761-L20AWA-5A MicroLogix 1000 Programmable Controller

Overview
The Allen Bradley 1761-L20AWA-5A is a compact MicroLogix 1000 programmable logic controller designed for small industrial automation applications. It delivers reliable control performance for discrete control tasks, machine automation, and simple process handling. With integrated I/O and a compact footprint, it is suitable for control panels where space and stability are key requirements.

General Information
Part Number: 1761-L20AWA-5A

Manufacturer: Allen-Bradley (Rockwell Automation)

Brand: Allen-Bradley

Country of Origin: United States

Series: MicroLogix 1000

Product Type: Programmable Logic Controller (PLC)

I/O Configuration: Built-in digital input/output channels

Mounting Type: DIN rail or panel mounting

Programming Software: RSLogix 500 compatible

Controller Type: Fixed I/O compact PLC

Power Specifications
Input Voltage: 120/240 V AC (model dependent configuration)

Power Consumption: Approximately 20–30 W typical operation

Internal Power Supply: Integrated AC power supply module

Protection: Over-voltage and short-circuit protection built-in

Inrush Current: Controlled low surge start-up design

Communication & Interface
Communication Port: RS-232 serial interface

Protocol Support: DF1 communication protocol

Programming Interface: Serial programming port connection

Status Indicators: LED indicators for run, fault, and communication status

Expansion Capability: Limited expansion via compatible modules

Environmental
Operating Temperature: 0 to 55 °C

Storage Temperature: −40 to 85 °C

Humidity: 5% to 95% non-condensing

Vibration Resistance: Industrial-grade vibration tolerance

Installation Environment: Control cabinet installation required

Dimensions & Weight
Dimensions (H × W × D): 200 × 73 × 80 mm

Weight: 0.531 kg

Reliable Control for Efficient Industrial Performance.
