Allen Bradley 1761-NET-DNI DeviceNet Interface Module

Overview
The Allen Bradley 1761-NET-DNI is a DeviceNet interface module designed to connect MicroLogix controllers to DeviceNet networks. It enables efficient data exchange between PLCs and distributed I/O devices, drives, and other networked components. Its compact design supports easy integration into industrial control systems requiring scalable communication.

General Information
Part Number: 1761-NET-DNI

Manufacturer: Allen-Bradley (Rockwell Automation)

Brand: Allen-Bradley

Country of Origin: United States

Series: MicroLogix Communication Modules

Product Type: DeviceNet Interface Module

Function: Network communication adapter

Mounting Type: Panel or DIN rail mounting

Application: DeviceNet network integration for MicroLogix systems

Power Specifications
Input Voltage: 24 V DC (network or external supply depending on system design)

Power Consumption: Low power operation (< 5 W typical)

Protection: Electrical isolation and surge protection built in

Internal Design: Noise-resistant industrial communication circuitry

Status Indicators: LED indicators for network status and module activity

Communication & Interface
Network Type: DeviceNet industrial network

Communication Role: Enables PLC connection to DeviceNet devices

Data Handling: Supports cyclic I/O and explicit messaging

Diagnostics: Network status, error detection, and communication monitoring

Configuration: Addressing and setup via hardware switches and network tools

Environmental
Operating Temperature: 0 to 55 °C

Storage Temperature: −40 to 85 °C

Humidity: 5% to 95% non-condensing

Vibration Resistance: Suitable for industrial automation environments

Installation Requirement: Control cabinet mounting required

Dimensions & Weight
Dimensions (H × W × D): 118 × 52.07 × 64.8 mm

Weight: 0.23 kg

Fast integration.
