Allen Bradley 1769-IQ6XOW4 CompactLogix Compact I/O Digital Combination Module

Overview

The Allen Bradley 1769-IQ6XOW4 is a CompactLogix combination digital I/O module designed to integrate both DC input and relay output functions within a single compact unit. It is commonly used in industrial automation systems where space efficiency and flexible signal control are required, enabling both signal monitoring and actuator control from one module.

General Information

Part Number: 1769-IQ6XOW4

Manufacturer: Allen-Bradley (Rockwell Automation)

Brand: Allen-Bradley

Country of Origin: USA

Series: CompactLogix 1769

Type: Digital Combination I/O Module (Input + Relay Output)

Function: Handles DC digital inputs and relay-based digital outputs for PLC control

Mounting: Installed on CompactLogix 1769 I/O chassis or DIN rail system

Technology: Opto-isolated inputs with electromechanical relay output architecture

Power Specifications

Operating Voltage: 24V DC input signals / relay output switching capability

Backplane Power: Supplied via CompactLogix 1769 backplane

Power Consumption: Low power industrial I/O module

Output Rating: Relay outputs suitable for industrial control loads

Input Protection: Channel isolation and surge protection

Indicators: LED status indicators for input and output channels

Communication & Interface

Bus System: CompactLogix 1769 backplane communication

Input Channels: 6 DC digital input channels

Output Channels: 4 relay output channels

Signal Type: 24V DC input signals and relay-switched outputs

Data Transfer: Real-time input/output status communication with PLC processor

Diagnostics: Built-in module diagnostics and channel fault detection

Environmental

Operating Temperature: 0 to 60 °C

Storage Temperature: −40 to 85 °C

Humidity: 5% to 95% non-condensing

Vibration Resistance: Industrial control cabinet rated

Protection Rating: IP20 for enclosed panel installation use

Dimensions & Weight

Dimensions (H × W × D): 118 × 35 × 87 mm

Weight: 0.28 kg

Compact Control Meets Flexible Automation — Designed for Efficient System Integration!
