Allen Bradley 1769-OB16P CompactLogix 16-Point Fused Output Module

Overview

The Allen Bradley 1769-OB16P is a CompactLogix 16-point fused DC output module designed for protected switching of industrial loads. It provides built-in electronic fusing to enhance output protection and improve system reliability in demanding automation environments.

General Information

Part Number: 1769-OB16P

Manufacturer: Allen Bradley

Brand: Allen Bradley

Country of Origin: United States

Series: CompactLogix 1769 I/O

Product Type: Fused DC Digital Output Module

Output Channels: 16-point sourcing outputs

Mounting Type: 1769 Compact I/O rack system

Application: Industrial automation output control with protection

Power Specifications

Operating Voltage: 24 V DC nominal

Output Current: Up to 0.5 A per channel (load dependent)

Fusing Type: Electronic fused outputs with auto-reset capability

Backplane Power: Supplied via CompactLogix system backplane

Power Dissipation: Low thermal design

Isolation Voltage: Channel-to-backplane isolation

Protection Features: Short-circuit protection, electronic fuse per channel

Status Indicators: LED indicators per channel and module status

Communication & Interface

System Integration: CompactLogix 1769 backplane communication

Control Method: PLC-controlled discrete switching

Diagnostics: Individual channel fault detection and fuse status monitoring

Response Time: Fast backplane update cycle

Wiring Interface: Removable terminal block for easy installation

Environmental

Operating Temperature: 0 to +60 °C

Storage Temperature: −40 to +85 °C

Relative Humidity: 5% to 95% non-condensing

Vibration Resistance: Industrial-grade vibration tolerance

Shock Resistance: Suitable for harsh industrial environments

Protection Rating: Installed inside industrial control enclosure

Dimensions & Weight

Dimensions (H × W × D): 118 × 35 × 87 mm

Weight: 0.255 kg

Smart protection, steady performance, built for uptime!
