Allen Bradley 1769-OW16 CompactLogix 16-Point AC/DC Relay Output Module

Overview

The Allen Bradley 1769-OW16 is a CompactLogix 16-point relay output module designed for flexible AC and DC load switching in industrial automation systems. It uses mechanical relay contacts to provide electrical isolation and universal output compatibility.

General Information

Part Number: 1769-OW16

Manufacturer: Allen Bradley

Brand: Allen Bradley

Country of Origin: United States

Series: CompactLogix 1769 I/O

Product Type: Relay Output Module

Output Channels: 16-point relay outputs

Contact Type: AC/DC relay switching

Mounting Type: 1769 Compact I/O rack system

Application: General-purpose industrial load control

Power Specifications

Operating Voltage: Supports AC/DC load switching via relay contacts

Contact Rating: Suitable for both AC and DC industrial loads (within relay limits)

Backplane Power: Supplied via CompactLogix system backplane

Power Dissipation: Low module consumption, relay-driven output

Isolation Voltage: High isolation provided by relay contacts

Protection Features: Arc suppression and contact protection design

Status Indicators: LED indicators for each channel and module status

Communication & Interface

System Integration: CompactLogix 1769 backplane communication

Control Method: PLC-controlled relay actuation

Response Time: Mechanical relay switching response

Diagnostics: Channel status monitoring and module diagnostics

Wiring Interface: Removable terminal block for field wiring

Environmental

Operating Temperature: 0 to +60 °C

Storage Temperature: −40 to +85 °C

Relative Humidity: 5% to 95% non-condensing

Vibration Resistance: Industrial-grade tolerance

Shock Resistance: Suitable for industrial control environments

Protection Rating: Installed inside control cabinet

Dimensions & Weight

Dimensions (H × W × D): 118 × 52.5 × 87 mm

Weight: 0.45 kg

Flexible switching, built for dependable industrial control!
