Allen Bradley 1769-OW8I CompactLogix 8-Point Relay Output Module

Overview

The Allen Bradley 1769-OW8I is a CompactLogix 8-point relay output module designed for isolated and flexible AC/DC load switching in industrial automation systems. It uses mechanical relay outputs to provide galvanic isolation and reliable control of field devices.

General Information

Part Number: 1769-OW8I

Manufacturer: Allen Bradley

Brand: Allen Bradley

Country of Origin: United States

Series: CompactLogix 1769 I/O

Product Type: Isolated Relay Output Module

Output Channels: 8-point relay outputs

Contact Type: AC/DC relay switching with isolation

Mounting Type: 1769 Compact I/O rack system

Application: Industrial automation and general-purpose load control

Power Specifications

Operating Voltage: Supports AC/DC switching via relay contacts

Contact Rating: Suitable for standard industrial load switching within relay limits

Backplane Power: Supplied via CompactLogix system backplane

Power Dissipation: Low module consumption, relay-based output operation

Isolation Voltage: High galvanic isolation via relay contacts

Protection Features: Arc suppression and contact protection design

Status Indicators: LED indicators for channel status and module health

Communication & Interface

System Integration: CompactLogix 1769 backplane communication

Control Method: PLC-controlled relay actuation

Response Time: Mechanical relay switching response

Diagnostics: Channel status and module fault detection

Wiring Interface: Removable terminal block for field wiring

Environmental

Operating Temperature: 0 to +60 °C

Storage Temperature: −40 to +85 °C

Relative Humidity: 5% to 95% non-condensing

Vibration Resistance: Industrial-grade vibration tolerance

Shock Resistance: Suitable for industrial control environments

Protection Rating: Installed inside industrial enclosure

Dimensions & Weight

Dimensions (H × W × D): 118 × 35 × 87 mm

Weight: 0.29 kg

Reliable relay switching, compact design, built for industrial performance!
