Allen Bradley 1783-LMS5 Stratix 2500 Lightly Managed Ethernet Switch

Overview

The Allen Bradley 1783-LMS5 is a Stratix 2500 lightly managed industrial Ethernet switch designed to provide reliable network connectivity in automation and control environments. It delivers stable data transmission, basic management functions, and enhanced network segmentation for industrial Ethernet systems requiring dependable communication performance.

General Information

Part Number: 1783-LMS5

Manufacturer: Allen-Bradley (Rockwell Automation)

Brand: Allen-Bradley

Country of Origin: USA

Series: Stratix 2500

Type: Lightly Managed Industrial Ethernet Switch

Installation: DIN rail or control cabinet mounting

Function: Industrial Ethernet switching and basic network management

Technology: Ethernet IEEE 802.3, industrial networking protocols support

Power Specifications

Supply Voltage: 24 V DC

Power Consumption: Low-power industrial design (typically ≤ 10 W)

Input Type: External DC power supply

Protection: Overvoltage, surge, and reverse polarity protection

Status Indicators: Power, link, and activity LED indicators

Communication & Interface

Ethernet Ports: Multiple RJ45 10/100 Mbps ports

Network Type: Industrial Ethernet (EtherNet/IP compatible)

Switching Mode: Store-and-forward switching architecture

Management Features: Basic configuration, port monitoring, and diagnostics

Diagnostics: Link status, traffic activity, and fault indication

Network Function: Supports segmentation and stable data routing

Environmental

Operating Temperature: −20 to +60 °C

Storage Temperature: −40 to +85 °C

Humidity: 5% to 95% RH, non-condensing

Protection Rating: IP20 industrial enclosure use

Vibration Resistance: Designed for standard industrial environments

Dimensions & Weight

Dimensions (H × W × D): 144.8 × 38.1 × 115 mm

Weight: 1.35 kg

Engineered for reliable industrial networking with consistent uptime and performance.
