Allen Bradley 1794-OE12 Flex I/O Analog Output Module

Overview
Allen Bradley 1794-OE12 Flex I/O Analog Output Module is a Flex I/O analog output module designed to deliver precise voltage or current signals for industrial process control applications. It is commonly used in distributed automation systems where accurate analog signal generation is required for actuators, drives, and control devices.

General Information
Part Number: 1794-OE12
Manufacturer: Rockwell Automation
Brand: Allen-Bradley
Country of Origin: USA
Series: Flex I/O (1794 Series)
Module Type: Analog Output Module
Output Type: Multi-channel analog output
Installation: DIN rail mounted via Flex I/O terminal base
Function: Precision analog signal output for process control systems

Power Specifications
Supply Voltage: 24 V DC (via Flex I/O backplane)
Power Consumption: 3–5 W typical
Input Power Source: Backplane-powered system
Isolation: Channel-to-backplane isolation
Protection: Over-voltage and transient protection
Status Indicators: LED module and channel status indicators

Communication & Interface
Backplane Communication: Flex I/O distributed I/O system
Compatible Networks: EtherNet/IP, ControlNet, DeviceNet (via adapters)
Configuration Platform: Studio 5000 / RSLogix
Signal Output: Configurable analog voltage/current signals
Diagnostics: Channel fault detection and signal integrity monitoring
System Integration: PLC-based distributed control architecture

Environmental
Operating Temperature: -20 to +60 °C
Storage Temperature: -40 to +85 °C
Humidity: 5% to 95% non-condensing
Vibration Resistance: IEC industrial standard compliant
Protection Rating: IP20
Pollution Degree: 2

Dimensions & Weight
Dimensions: 94 × 46 × 54 mm
Weight: 0.106 kg

Precision analog control engineered for reliable and efficient industrial automation performance.
