Allen Bradley 20-750-ENC-1 PowerFlex 750 Incremental Encoder Module

Overview

The Allen Bradley 20-750-ENC-1 is an incremental encoder feedback module designed for PowerFlex 750 series AC drives. It provides accurate motor speed and position feedback, helping improve drive performance in applications requiring precise motion control.

This module is commonly used in industrial automation systems such as conveyors, positioning equipment, and machine control applications where reliable encoder feedback is required.

General Information

Part Number: 20-750-ENC-1

Manufacturer: Allen Bradley

Brand: Allen Bradley

Country of Origin: United States

Series: PowerFlex 750 Series

Type: Incremental Encoder Feedback Module

Application: Motor speed feedback and position control

Installation: Mounted inside compatible PowerFlex 750 series drives

Function: Provides encoder signal feedback for improved motor control accuracy and drive performance

Compatibility: PowerFlex 753 and PowerFlex 755 AC drives

Technology: High-resolution encoder interface with integrated feedback monitoring

Power Specifications

Supply Voltage: 5 V DC or 12 V DC encoder power supply

Power Source: Supplied through the PowerFlex drive control system

Power Consumption: Low-power operation for encoder feedback processing

Protection: Designed for reliable operation in industrial electrical environments

Indicators: LED status indicators for module operation and feedback diagnostics

Communication & Interface

Feedback Interface: Incremental encoder input

Input Type: Quadrature encoder signals (A, B, and optional Z channels)

Encoder Support: Supports motor speed and position feedback applications

Connection Method: Terminal-based encoder signal connection

Control Function: Improves speed regulation, positioning accuracy, and closed-loop drive control

Diagnostics: Provides feedback status monitoring and fault detection through drive parameters

Environmental

Operating Temperature: 0 to +50 °C

Storage Temperature: −40 to +85 °C

Relative Humidity: 5 to 95% RH, non-condensing

Installation Environment: Industrial automation cabinets and drive control systems

Protection Rating: Suitable for standard PowerFlex drive operating environments

Resistance: Designed to withstand industrial vibration, electrical noise, and continuous operation conditions

Dimensions & Weight

Dimensions (L × W × H): 150 × 26 × 68 mm

Weight: 0.068 kg
