Allen Bradley 20F1ANC302JA0NNNNN PowerFlex 753 AC Drive

Overview

The Allen Bradley 20F1ANC302JA0NNNNN PowerFlex 753 AC Drive is a high-power variable frequency drive designed for demanding industrial motor control applications. It provides reliable performance, advanced control capabilities, flexible system integration, and comprehensive protection functions for large-scale automation systems.

This drive is suitable for heavy-duty applications such as large conveyors, pumps, fans, compressors, and industrial processing equipment requiring efficient and precise AC motor control.

General Information

Part Number: 20F1ANC302JA0NNNNN

Manufacturer: Allen Bradley

Brand: Allen Bradley

Country of Origin: USA

Series: PowerFlex 753

Type: AC Variable Frequency Drive (VFD)

Input Voltage Class: 480 VAC

Rated Output Current: 302 A

Motor Control: Sensorless Vector Control, Vector Control, and Volts/Hertz Control

Mounting: Panel mounting inside industrial control cabinets

Application: Heavy-duty industrial motor control and automation systems

Protection Features: Overvoltage, undervoltage, overload, short circuit, and thermal protection

Power Specifications

Input Voltage: 480 VAC three-phase

Input Frequency: 50/60 Hz

Output Voltage: 0 to rated input voltage

Output Frequency Range: 0 to 590 Hz

Rated Output Power: Approximately 250 kW / 400 HP class

Overload Capacity: Supports normal duty and heavy-duty overload operation

Cooling Method: Forced air cooling

Protection Functions: Integrated monitoring for current, voltage, temperature, and drive faults

Communication & Interface

Communication Ports: Supports optional communication modules

Network Options: EtherNet/IP and other industrial communication networks

Control Inputs: Digital and analog inputs for start, stop, speed reference, and feedback signals

Control Outputs: Relay and analog outputs for drive status monitoring

Operator Interface: Supports HIM keypad for setup, programming, and diagnostics

Programming: Parameter configuration through keypad, software tools, or network connection

Diagnostic Functions: Provides fault alarms, event logs, and real-time drive status monitoring

Environmental

Operating Temperature: 0 to 50 °C

Storage Temperature: −40 to +85 °C

Humidity: 5 to 95% RH, non-condensing

Altitude: Up to 1000 m without derating

Installation Environment: Indoor industrial control cabinet

Protection Rating: IP20 / NEMA open type

Vibration Resistance: Suitable for standard industrial automation environments

Dimensions & Weight

Dimensions (H × W × D): 881.5 × 349.6 × 430 mm

Weight: 79 kg

Powerful Control for Advanced Industrial Systems!
