Allen Bradley 5069-IB16 Compact 5000 Digital Sinking Input Module

Overview

The Allen Bradley 5069-IB16 Compact 5000 Digital Sinking Input Module is a compact digital input module designed for monitoring field devices in industrial automation systems. It provides reliable signal acquisition from sensors, switches, and other input devices, enabling efficient integration with CompactLogix controllers and distributed I/O architectures.

General Information

Part Number: 5069-IB16

Manufacturer: Allen Bradley

Brand: Allen Bradley

Country of Origin: United States

Series: Compact 5000 I/O

Product Type: Digital Sinking Input Module

Mounting: DIN Rail Mount

Application: Industrial Signal Monitoring, Machine Control, and Distributed I/O Systems

Function: Receives digital input signals from field devices and transfers data to the controller system

Power Specifications

Supply Voltage: 24 V DC

Input Type: Digital DC Sinking Input

Input Channels: 16 Channels

Power Consumption: Low Power I/O Module Design

Protection: Short Circuit, Overvoltage, and Reverse Polarity Protection

Status Indicators: Individual Channel Status LEDs and Module Status LEDs

Communication & Interface

Backplane Interface: Compact 5000 I/O System Connection

Communication Protocol: EtherNet/IP Through Adapter Module

Input Signal Type: DC Digital Input Signals

Configuration Software: Studio 5000 Logix Designer

Diagnostics: Channel-Level Status Monitoring and Fault Detection

System Integration: Supports CompactLogix and ControlLogix Automation Platforms

Environmental

Operating Temperature: -20°C to +60°C

Storage Temperature: -40°C to +85°C

Humidity: 5% to 95% RH, Non-Condensing

Protection Rating: IP20

Installation Environment: Industrial Control Cabinet

Dimensions & Weight

Dimensions (W × H × D): 144.6 × 22 × 105.4 mm

Weight: 0.175 kg
