Allen Bradley 5069-IF8 Compact 5000 Analog Current/Voltage Input Module

Overview

The Allen Bradley 5069-IF8 Compact 5000 Analog Current/Voltage Input Module is a high-precision analog input module designed for monitoring industrial process signals. It supports current and voltage measurements from field devices, providing accurate data acquisition for process control, machine monitoring, and advanced automation applications.

General Information

Part Number: 5069-IF8

Manufacturer: Allen Bradley

Brand: Allen Bradley

Country of Origin: United States

Series: Compact 5000 I/O

Product Type: Analog Current/Voltage Input Module

Mounting: DIN Rail Mount

Application: Process Monitoring, Analog Signal Acquisition, and Industrial Control Systems

Function: Converts analog field signals into digital data for controller processing

Power Specifications

Supply Voltage: 24 V DC

Input Type: Analog Current and Voltage Input

Input Channels: 8 Analog Input Channels

Signal Range: Configurable Current and Voltage Signals

Power Consumption: Low Power I/O Module Design

Protection: Overvoltage, Short Circuit, and Channel Diagnostic Protection

Status Indicators: Module Status and Channel Status LEDs

Communication & Interface

Backplane Interface: Compact 5000 I/O System Connection

Communication Protocol: EtherNet/IP Through Adapter Module

Input Signal Type: Analog Current and Voltage Signals

Configuration Software: Studio 5000 Logix Designer

Data Processing: High-Resolution Analog Signal Conversion

Diagnostics: Channel-Level Monitoring, Status Reporting, and Fault Detection

Environmental

Operating Temperature: -20°C to +60°C

Storage Temperature: -40°C to +85°C

Humidity: 5% to 95% RH, Non-Condensing

Protection Rating: IP20

Installation Environment: Industrial Control Cabinet

Dimensions & Weight

Dimensions (W × H × D): 144.6 × 22 × 105.4 mm

Weight: 0.175 kg

In Stock Now – Fast Shipping and Reliable Automation Components.
