Allen Bradley 5069-OF8 Compact 5000 Analog Output Module

Overview

The Allen Bradley 5069-OF8 Compact 5000 Analog Output Module is a high-performance analog output module engineered for precise process control and industrial automation applications. It delivers stable analog current and voltage signals, making it ideal for controlling variable frequency drives, control valves, actuators, and other analog field devices in modern automation systems.

General Information

Part Number: 5069-OF8

Manufacturer: Allen Bradley

Brand: Allen Bradley

Country of Origin: United States

Series: Compact 5000 I/O

Product Type: Analog Output Module

Module Type: Analog Output I/O Module

Mounting Method: DIN Rail Mount

Application: Process Automation, Machine Control, Industrial I/O Systems

Power Specifications

Supply Voltage: 24 V DC

Power Consumption: Low Power Industrial Operation

Output Channels: 8 Analog Output Channels

Output Signal: Configurable Current and Voltage Outputs

Channel Isolation: Individually Isolated Outputs

Protection Features: Overvoltage Protection, Short-Circuit Protection, Output Diagnostics

Status Indicators: LED Indicators for Power, Module Status, and Fault Conditions

Communication & Interface

Communication Interface: Compact 5000 I/O Backplane

Configuration: Software Configurable via Studio 5000 Logix Designer

Signal Types: Current and Voltage Output Support

Module Diagnostics: Real-Time Channel Monitoring and Fault Reporting

Compatibility: CompactLogix 5380 Controllers and Compact 5000 I/O Systems

Integration: Supports High-Speed Distributed Industrial Automation Networks

Environmental

Operating Temperature: -20°C to +60°C

Storage Temperature: -40°C to +85°C

Relative Humidity: 5% to 95% RH, Non-Condensing

Protection Rating: IP20

Installation Environment: Industrial Control Cabinet

Dimensions & Weight

Dimensions (W × H × D): 144.57 × 25.56 × 109.09 mm

Weight: 0.175 kg

Dependable Industrial Components with Rapid Worldwide Shipping.
