Overview
The ABB BPCB-01C is a capacitor board used in power electronics and control systems. It stores and releases charge to help stabilize voltage, filter noise, and support transient suppression within ABB drive or breaker equipment.
General Information
Part Number: 3AXD50000000331
Brand / Country of Origin: ABB / Sweden
Manufacturer: ABB
Series: BPCB
Type: Capacitor Board
Power Specifications
It functions as a passive capacitor component, not requiring its own power supply.
It supports high-voltage DC or AC environments, depending on system application.
Protection is achieved through its internal capacitance and design, which helps absorb and filter system transients.
No active indicators are present on the board itself.
Communication & Interface
The board does not communicate digitally; it integrates simply through power and ground terminals.
It interfaces with the main control or power circuit to provide energy absorption and smoothing.
Its role is purely electrical: to store charge and act as a stabilizer in switching systems.
Environmental
Operating Temperature: Designed for typical industrial cabinet environments
Humidity: Suitable for non-condensing conditions
Installation Area: Mounted inside power or control modules, typically within drive or protection housing
Durability: Built to withstand electrical stress and frequent transient events
Dimensions & Weight
Dimensions (L × W × H): Approx. 120 × 60 × 25 mm
Weight: ~0.1 kg
