Overview
The ABB CI630 is a high-capacity communication interface module that facilitates data exchange between the controller and field I/O devices in ABB distributed control systems. It is suited for advanced automation tasks and supports robust diagnostic communication.
General Information
Part Number: 3BSE011000R1
Manufacturer: ABB
Series: CI (Communication Interface)
Type: Bus / Interface Module
Mounting: Rack installation in control panel
Technology: Embedded control bus logic, diagnostics, and signal routing
Country of Origin: Sweden
Power Specifications
Supply Voltage: 24 V DC
Power Consumption: Moderate, designed for continuous high-load communication
Protection: Surge protection and reverse-polarity protection included
Indicators: LED indicators for power, communication, and fault status
Communication & Interface
Bus Mechanism: Control bus for field communication
Role: Bridges the controller with I/O modules and field devices
Diagnostics: Communication error detection, link supervision, status reporting
Operator Interface: LEDs for module condition and activity
Reset Features: Supports both software and hardware reset
I/O & Channels
Relay Channels: None (communication-only module)
External Load Support: Not applicable
Environmental
Operating Temperature: -40 to +70 °C
Humidity: Up to 95% RH, non-condensing
Protection Rating: IP20 in control cabinet
Dimensions & Weight
Dimensions (L × W × H): 252 × 273 × 40 mm
Weight: ~ 1.42 kg
