ABB DATX100 3ASC25H208 | Pulse Transformer Quality Assurance

Overview
The ABB DATX100 is a high-performance Pulse Transformer, designed to provide reliable and accurate signal transmission in industrial automation systems. This transformer is optimized for use in applications requiring precise pulse signal conversion, such as data acquisition, signal conditioning, and control systems. The DATX100 ensures efficient and stable operation in demanding environments, enabling seamless communication between control systems and field devices. It is widely used in industries such as manufacturing, power generation, and chemical processing, where reliable pulse signal processing is essential for system performance and accuracy.

General Information
Part Number: 3ASC25H208
Manufacturer: ABB
Country of Origin: Sweden
Series: DATX (Pulse Transformer)
Type: Pulse Transformer
Mounting: Suitable for installation in control cabinets or automation racks
Technology: Pulse signal conversion, high-precision transmission

Power Specifications
Supply Voltage: 24 V DC
Power Consumption: ≤ 10 W
Input: Powered from the system backplane or external power supply
Indicators: LEDs for power and operational status
Protection: Over-voltage and short-circuit protection

Communication & Interface
Communication Interface: Compatible with industrial control systems for pulse signal integration
Diagnostics: Built-in diagnostics for operational status and fault detection
Operator Interface: Configurable for external HMI or integrated control system
Reset Features: Supports reset functionality to restore operation after fault conditions

Environmental
Operating Temperature: −20 to +60 °C
Humidity: Up to 95% RH, non-condensing
Protection Rating: IP20, suitable for industrial environments

Dimensions & Weight
Dimensions (L × W × H): 215 × 200 × 35 mm
Weight: ~ 1.06 kg

Authentic parts with full manufacturer warranty.
