Overview
The ABB PM150 is a Processor Module designed to perform high-speed data processing and control functions in industrial automation systems. It serves as the central computing unit, managing system operations, executing control logic, and coordinating communication between connected modules and field devices. The PM150 ensures reliable performance and stability in demanding industrial environments, making it suitable for applications such as process control, energy management, and automated manufacturing.
General Information
Part Number: 3BSE003641R1
Manufacturer: ABB
Brand / Country of Origin: ABB / Sweden
Series: PM (Processor Module)
Type: Processor Module
Mounting: Suitable for installation in control panels, automation racks, or system enclosures
Technology: Industrial-grade processing for real-time control and data management
Power Specifications
Supply Voltage: 24 V DC
Power Consumption: ≤ 10 W
Input: Powered from system backplane or external DC supply
Indicators: LEDs for power and operational status
Protection: Over-voltage, over-current, and short-circuit protection
Communication & Interface
Interface Type: Backplane and industrial communication protocols
System Role: Executes control programs and manages data exchange between modules
Signal Handling: Real-time processing of digital and analog I/O signals
Diagnostics: Built-in diagnostics for system health and fault detection
Reset Features: Supports CPU and system-level reset functions
Environmental
Operating Temperature: −20 to +60 °C
Humidity: Up to 95% RH, non-condensing
Protection Rating: IP20, suitable for industrial cabinet installation
Dimensions & Weight
Dimensions (L × W × H): 120 × 90 × 60 mm
Weight: ~ 2.8 kg
Authentic parts with full manufacturer warranty.
