Overview
The ABB PM153 is an Advant Controller designed for advanced industrial automation systems. It serves as a central processing and control unit, managing I/O operations, executing control logic, and coordinating communication between connected modules and field devices. The PM153 ensures precise and reliable operation, making it suitable for demanding applications such as process control, energy management, and automated manufacturing.
General Information
Part Number: 3BSE003644R1
Manufacturer: ABB
Brand / Country of Origin: ABB / Sweden
Series: PM (Advant Controller)
Type: Advant Controller
Mounting: Installed in control panels, automation racks, or system enclosures
Technology: Industrial-grade processor and controller for real-time monitoring and system management
Power Specifications
Supply Voltage: 24 V DC
Power Consumption: ≤ 12 W
Input: Powered from system backplane or external DC supply
Indicators: LEDs for power, status, and operational monitoring
Protection: Over-voltage, over-current, and short-circuit protection
Communication & Interface
Interface Type: Backplane and industrial communication protocols
System Role: Executes control programs, manages I/O, and facilitates module communication
Signal Handling: Real-time processing of digital and analog signals
Diagnostics: Built-in diagnostics for operational status and fault detection
Reset Features: Supports controller and system-level reset functions
Environmental
Operating Temperature: −20 to +60 °C
Humidity: Up to 95% RH, non-condensing
Protection Rating: IP20, suitable for industrial control cabinets
Dimensions & Weight
Dimensions (L × W × H): 236 × 226 × 2 mm
Weight: ~ 0.34 kg
Authentic parts with full manufacturer warranty.
