Overview
The ABB 5SHY4045L0004 is an Integrated Gate Commutated Thyristor (IGCT) module, designed to provide high-efficiency, fast switching, and precise control of power in industrial and energy systems. IGCTs combine the benefits of both thyristor and transistor technologies, offering superior performance in high-voltage applications. This module is particularly suited for use in energy management, motor drives, and power electronics, providing reliable and efficient control in applications that require high-speed switching of large power loads. With its robust design, the 5SHY4045L0004 ensures long-term reliability and smooth integration into ABB's power control systems.
General Information
Part Number: 3BHB021400R0002
Manufacturer: ABB
Brand / Country of Origin: ABB / Sweden
Series: 5SHY (Integrated Gate Commutated Thyristor)
Type: IGCT Module
Mounting: Suitable for installation in high-voltage power control systems, motor drives, and industrial power electronics
Technology: Advanced IGCT technology for fast and reliable power switching
Power Specifications
Supply Voltage: 24 V DC
Power Consumption: ≤ 30 W
Input: Powered from system backplane or external DC supply
Indicators: LEDs for power, operational status, and communication
Protection: Over-voltage, over-current, and short-circuit protection
Communication & Interface
Interface Type: Industrial communication protocols (e.g., Fieldbus, Profibus, Ethernet)
System Role: Efficient control and switching of power in industrial and high-voltage applications
Signal Handling: Real-time power regulation and switching of large power loads
Diagnostics: Built-in diagnostics for monitoring operational status, performance, and fault detection
Reset Features: Supports reset functions at the module level
Environmental
Operating Temperature: −20 to +60 °C
Humidity: Up to 95% RH, non-condensing
Protection Rating: IP20, designed for use in industrial environments
Dimensions & Weight
Dimensions (L × W × H): 350 × 290 × 60 mm
Weight: ~ 2.64 kg
Professional 24/7 customer support available.
