Overview
The ABB PM630 is a robust and high-performance CPU module designed for industrial automation systems. Serving as the core of control systems, it executes complex control algorithms, processes input/output data, and manages communication between various modules and devices. The PM630 is ideal for applications requiring high-speed processing, real-time control, and precise coordination of operations in industrial environments, including manufacturing, energy management, and process control systems.
General Information
Part Number: 3BSE000434R1
Manufacturer: ABB
Brand / Country of Origin: ABB / Sweden
Series: PM (CPU Module)
Type: CPU Module
Mounting: Suitable for installation in control panels, automation racks, or system enclosures
Technology: Industrial-grade processor for real-time control, data processing, and system management
Power Specifications
Supply Voltage: 24 V DC
Power Consumption: ≤ 15 W
Input: Powered from system backplane or external DC supply
Indicators: LEDs for power, operational status, and communication
Protection: Over-voltage, over-current, and short-circuit protection
Communication & Interface
Interface Type: Backplane and industrial communication protocols
System Role: Executes control logic, manages I/O, and coordinates system communications
Signal Handling: Processes digital and analog signals for seamless communication and control
Diagnostics: Built-in diagnostics for real-time monitoring, error detection, and fault reporting
Reset Features: Supports module-level and system-level reset functions
Environmental
Operating Temperature: −20 to +60 °C
Humidity: Up to 95% RH, non-condensing
Protection Rating: IP20, suitable for industrial environments
Dimensions & Weight
Dimensions (L × W × H): 120 × 90 × 60 mm
Weight: ~ 0.5 kg
Authentic parts with full manufacturer warranty.
