ABB GVC704AE01 3BHB003230R0101 | IGCT Module Quality Assurance

Overview
The ABB GVC704AE01 is an IGCT module designed for ABB’s industrial drive and power conversion systems. It integrates high-performance Integrated Gate-Commutated Thyristor technology, providing efficient power switching, precise control, and reliable operation in high-power applications.

General Information
Part Number: 3BHB003230R0101
Manufacturer: ABB
Brand / Country of Origin: ABB / Switzerland
Series: GVC
Type: IGCT Module
Mounting: Mechanical mounting within power and drive assemblies
Technology: IGCT-based power semiconductor module with integrated gate and protection design

Power Specifications
Operating Voltage: High-voltage power semiconductor operation
Current Handling: Designed for high-current industrial applications
Power Loss: Optimized for low switching and conduction losses
Protection: Integrated protection for overcurrent and abnormal operating conditions

Communication & Interface
Control Interface: Dedicated gate and control signal connections
Integration: Designed for seamless integration with ABB drive and control systems
Monitoring: Status and operational condition feedback
Diagnostics: Supports system-level fault detection and monitoring

Environmental
Operating Temperature: −10 to +55 °C
Storage Temperature: −25 to +70 °C
Humidity: Up to 95% RH, non-condensing
Cooling Requirement: Forced air or liquid cooling depending on system design

Dimensions & Weight
Dimensions: 22x124x126 mm
Weight: 0.1kg

Tested and verified before shipment.
