The ABB PM864 (3BSE018151R1) is a high-performance processor module within the AC 800M series, part of the Advant 800xA system. It is designed to handle complex control tasks, manage communication interfaces, and coordinate I/O modules, making it suitable for demanding industrial automation applications.
General Information
Part Number: 3BSE018151R1
Manufacturer: ABB Ltd.
Brand Origin: Sweden
Series: AC 800M
Type: Processor / CPU Module
Mounting: DIN rail or baseplate installation
Application: Core controller for distributed control and PLC systems
Power Specifications
Supply Voltage: 24 V DC
Power Consumption: Approx. 7 W
Protection: Overvoltage and reverse polarity protection
Indicators: LEDs for power, status, and communication
Communication & Interface
Ethernet Ports: 2 × 10/100 Mbps
Serial Ports: 1 × RS-232 for configuration and diagnostics
Supported Protocols: Modbus TCP, PROFIBUS, EtherNet/IP, OPC
Redundancy: Supported for high-availability configurations
Diagnostics: System status monitoring, error detection, and event logging
Configuration: Managed via ABB Control Builder software
Environmental
Operating Temperature: −20 °C to +60 °C
Storage Temperature: −40 °C to +85 °C
Humidity: 5% to 95% RH, non-condensing
Protection Class: IP20
Dimensions & Weight
Dimensions: 186 × 119 × 135 mm
Weight: 1.2 kg
