Overview
The ABB 216DB61 HESG324063R100 is a binary input and trip unit designed for use in ABB industrial control and protection systems. It is responsible for monitoring digital input signals and initiating protective trip actions when specific conditions are detected.
This module plays a critical role in safeguarding industrial processes and equipment by ensuring that abnormal signals or fault conditions trigger immediate system responses. Its robust design and reliable performance make it suitable for applications in power generation, process automation, and heavy industrial environments.
General Information
Part Number: HESG324063R100
Model Number: 216DB61
Manufacturer: ABB
Brand: ABB
Country of Origin: Switzerland
Series: ABB industrial control and protection modules
Type: Binary Input and Trip Unit
Mounting: Rack or panel installation within industrial control cabinets
Technology: Digital signal monitoring with integrated protection and trip functionality
Power Specifications
Supply Voltage: 24 V DC
Power Consumption: ≤ 6 W
Power Source: Powered via the control system backplane or interface connection
Protection: Built-in over-current and surge protection
Indicators: LED indicators for power status, input activity, and trip conditions
Communication & Interface
System Interface: Direct integration with ABB control and protection systems
Input Channels: Binary digital input channels for monitoring field signals
Trip Function: Generates protective trip signals when predefined conditions are met
Diagnostics: Continuous monitoring of input status and module health
Configuration: Adjustable parameters through ABB engineering and configuration tools
Status Monitoring: Front-panel LED indicators for signal and trip status
Environmental
Operating Temperature: −40 to +70 °C
Storage Temperature: −40 to +85 °C
Humidity: Up to 95% RH, non-condensing
Protection Rating: Designed for installation inside industrial control cabinets
Vibration Resistance: Suitable for demanding industrial automation environments
Dimensions & Weight
Dimensions (L × W × H): 160 × 50 × 100 mm
Weight: 0.5 kg
