ABB DSAI 130 57120001-P DS Analog Input Unit

Overview

The ABB DSAI 130 is a high-precision analog input unit designed for signal acquisition in ABB distributed control systems. It collects analog signals from field devices such as transmitters, sensors, and measurement instruments, converting them into digital data for system monitoring and control. Engineered for stability and accuracy, the module supports reliable process measurement in demanding industrial automation environments.

General Information

Part Number: 57120001-P

Manufacturer: ABB

Brand: ABB

Country of Origin: Switzerland

Series: DS Series I/O

Type: Analog Input Unit

Application: Industrial automation, process monitoring, and distributed control systems (DCS)

Mounting: Installed within ABB controller racks or I/O cabinets

Technology: High-accuracy analog signal acquisition with integrated diagnostics

Power Specifications

Supply Voltage: 24 V DC (provided through the system backplane)

Power Consumption: ≤ 8 W

Input Signal Types: Standard industrial analog signals from field transmitters and sensors

Signal Processing: High-resolution conversion with filtering for stable data acquisition

Protection: Designed with internal circuit protection for stable operation

Status Indicators: Operational status monitored through the control system interface

Communication & Interface

System Interface: Internal backplane communication with ABB controllers

Signal Interface: Accepts analog input signals from industrial measurement devices

Diagnostics: Input monitoring with system-level fault detection

Configuration: Configurable through ABB automation control software

Compatibility: Designed for ABB systems supporting DS Series I/O modules

Environmental

Operating Temperature: −25 to +70 °C

Storage Temperature: −40 to +85 °C

Relative Humidity: Up to 95% RH, non-condensing

Protection Rating: Intended for installation in protected industrial control cabinets

EMC Compliance: Meets industrial electromagnetic compatibility standards

Dimensions & Weight

Dimensions (L × W × H): 327.6 × 14.4 × 236.7 mm

Weight: Approximately 0.52 kg
