ABB DSDON001 Bus Control Unit

Overview

The ABB DSDON001 is a bus control unit designed for ABB DS (Distributed System) automation platforms. It manages communication between DS system modules, ensuring reliable data transfer and synchronization across the control network. The unit supports high-speed bus operations and fault-tolerant performance in industrial environments.

General Information

Part Number: DSDON001

Manufacturer: ABB

Brand / Country of Origin: ABB / Switzerland

Series: DS Bus Control Units

Type: Bus Control Unit

Mounting: DIN rail or backplane mounting within DS system racks

Technology: High-speed bus management, LED status indicators, fault diagnostics

Power Specifications

Supply Voltage: 24 V DC

Power Consumption: ≤ 12 W

Input: Powered from system backplane

Protection: Reverse polarity and short-circuit protection

Indicators: LEDs for bus status, module health, and fault conditions

Communication & Interface

Bus Interface: Connects and manages communication between DS system modules

Diagnostics: Bus activity monitoring, fault detection, and system alerts

Operator Interface: LED indicators for bus status and unit health

Reset Features: Supports system-level reset via controller commands

Environmental

Operating Temperature: −20 to +70 °C

Humidity: Up to 95% RH, non-condensing

Protection Rating: IP20 for industrial cabinet mounting

Vibration & Shock: Conforms to IEC 60068 industrial standards

Dimensions & Weight

Dimensions (L × W × H): 224 × 200 × 50 mm

Weight: ~ 0.5 kg
