Overview
The ABB PCD244A101 3BHE042816R0101 is a process control module developed for ABB’s industrial automation and drive systems. It ensures high-speed data communication, accurate signal processing, and stable control performance, making it suitable for complex process control applications.
General Information
Part Number: 3BHE042816R0101
Manufacturer: ABB
Brand / Country of Origin: ABB / Sweden
Series: PCD Series
Type: Process Control Module
Mounting: Rack-mounted module within control system chassis
Technology: Digital process control and communication integration
Power Specifications
Supply Voltage: 24 V DC
Power Consumption: ≤ 12 W
Input: Powered through the system backplane
Protection: Overvoltage, reverse polarity, and surge protection
Indicators: LEDs for power, operation, communication, and fault status
Communication & Interface
Communication Protocols: CAN, PROFIBUS, or ABB proprietary control bus
Interface Ports: Multi-pin connectors for data and signal communication
Diagnostics: Built-in self-diagnostics and communication monitoring
Operator Interface: LED status indicators
Reset Features: Supports hardware and software reset functions
Environmental
Operating Temperature: −40 to +70 °C
Humidity: Up to 95% RH, non-condensing
Protection Rating: IP20 (for installation inside control cabinet)
Dimensions & Weight
Dimensions (L × W × H): 234 × 27 × 112.5 mm
Weight: ~0.3 kg
