ABB LD MTR-01 3BHB007445P0001 Analog Input Card

Overview

The ABB LD MTR-01 is a high-precision analog input card designed for industrial automation systems. It accurately converts analog signals from field devices into digital data for monitoring and control, ensuring reliable system performance.

General Information

Part Number: 3BHB007445P0001

Manufacturer: ABB

Brand / Country of Origin: ABB / Switzerland

Series: LD

Type: Analog Input Card

Application: Signal acquisition and monitoring in industrial automation

Mounting: Card-mounted within control system chassis

Technology: High-resolution analog-to-digital conversion with integrated diagnostics

Power Specifications

Supply Voltage: 24 V DC

Power Consumption: ≤ 5 W

Input Power Source: System backplane

Protection: Overvoltage and reverse polarity protection

Indicators: LED indicators for power and channel status

Communication & Interface

System Interface: Direct connection to ABB control system backplane

Signal Interface: Multiple analog input channels for voltage and current signals

Supported Signals: 0–10 V, 4–20 mA

Diagnostics: Continuous self-monitoring and fault reporting

Configuration: Software-based parameter configuration

Isolation: Electrical isolation between input channels and system

Environmental

Operating Temperature: −20 to +60 °C

Storage Temperature: −40 to +85 °C

Humidity: Up to 95% RH, non-condensing

Protection Rating: IP20 (installed inside control cabinet)

EMC Compliance: Meets industrial electromagnetic compatibility standards

Dimensions & Weight

Dimensions (L × W × H): 120 × 90 × 45 mm

Weight: 0.3 kg

Precision Performance – Monitor Your System Accurately!
