ABB MBM200H45E2-H 3BHB032608R0001 IGBT Module

Overview

The ABB MBM200H45E2-H is a high-performance IGBT (Insulated Gate Bipolar Transistor) module designed for industrial power electronics applications. It provides fast switching, high efficiency, and reliable performance for motor drives, inverters, and power conversion systems.

General Information

Part Number: 3BHB032608R0001

Manufacturer: ABB

Brand / Country of Origin: ABB / Switzerland

Series: MBM

Type: IGBT Module

Application: Motor drives, inverters, and industrial power electronics

Mounting: Panel or heat-sink mounted within power modules

Technology: High-speed IGBT with integrated freewheeling diodes and thermal protection

Power Specifications

Collector-Emitter Voltage: 450 V

Collector Current: 200 A

Power Dissipation: Optimized for high-efficiency switching

Supply Voltage: Operates within standard industrial DC bus voltages

Protection: Overcurrent and thermal protection integrated

Indicators: None (module level monitoring via external system)

Communication & Interface

System Interface: Direct electrical integration into inverter or drive systems

Signal Interface: Gate drive signals for switching control

Diagnostics: Thermal and electrical monitoring supported via system-level diagnostics

Configuration: Configurable through drive control settings

Isolation: Electrically isolated collector and gate circuits

Environmental

Operating Temperature: −40 to +125 °C

Storage Temperature: −40 to +150 °C

Humidity: Up to 95% RH, non-condensing

Protection Rating: IP00 (requires enclosure or heat-sink for protection)

EMC Compliance: Meets industrial electromagnetic compatibility standards

Dimensions & Weight

Dimensions (L × W × H): 140 × 36.5 × 73 mm

Weight: 0.84 kg
