ABB PM901F 3BDH001001R0001 CPU Control Processor Main Unit

Overview

The ABB PM901F is a high-performance CPU control processor main unit designed for industrial automation systems. It provides fast, reliable processing and real-time control, making it ideal for complex process and factory automation applications. The unit is engineered for seamless integration with ABB’s control modules and field devices, ensuring robust and efficient operation.

General Information

Part Number: 3BDH001001R0001

Manufacturer: ABB

Brand / Country of Origin: ABB / Sweden

Series: PM (Process Module)

Type: CPU Control Processor Main Unit

Mounting: Rack or card-based installation within control cabinets

Technology: Industrial-grade microprocessor, real-time deterministic execution, integrated diagnostics

Power Specifications

Supply Voltage: 24 V DC

Power Consumption: ≤ 60 W

Input: Powered via backplane connection

Protection: Surge and reverse-polarity protection

Indicators: LEDs for power, CPU status, fault, and activity

Communication & Interface

Ethernet / Fieldbus Ports: Supports PROFIBUS, Modbus, and ABB proprietary bus systems

Bus Coupler Role: Connects controller bus to field devices and I/O modules

Diagnostics: CPU and network supervision, fault logging, status monitoring

Operator Interface: LED indicators and onboard configuration switches

Reset Features: Supports both soft and hardware reset

I/O & Channels: Integrated digital and analog I/O channels, expandable via connected modules

Environmental

Operating Temperature: 0 to +55 °C

Humidity: Up to 95% RH, non-condensing

Protection Rating: IP20 (suitable for industrial cabinet mounting)

Shock & Vibration: IEC 60068 compliant

Dimensions & Weight

Dimensions (L × W × H): 227 × 152 × 95 mm

Weight: 1.07 kg

⚡ Reliable Control, Designed for High-Performance Automation!
