ABB T60407-B4803-X010 3BHB004719R0001 Pulse Transformer

Overview

The ABB T60407-B4803-X010 is a pulse transformer designed for industrial automation and power electronics applications. It provides high-speed signal isolation and voltage conversion, ensuring reliable transmission of pulse signals while protecting sensitive components from electrical noise and interference.

General Information

Part Number: 3BHB004719R0001

Manufacturer: ABB

Brand / Country of Origin: ABB / Sweden

Type: Pulse Transformer / Signal Isolation Component

Series: T60407

Mounting: Panel or chassis installation

Technology: High-frequency magnetic core transformer for pulse signal transmission

Power Specifications

Primary Voltage: System dependent, typically low-voltage control signals

Secondary Voltage: Matched for pulse signal applications

Power Rating: Application-dependent, designed for signal-level currents

Protection: Electrical isolation between primary and secondary circuits

Indicators: None (passive component)

Communication & Interface

Interface Type: Pulse signal input/output

Connection: Screw terminals or pin connectors for integration with control circuits

Application Role: Provides isolated pulse signal transfer for industrial control systems, protecting sensitive electronics

Diagnostics: Not applicable (passive component)

Environmental

Operating Temperature: −20 to +70 °C

Storage Temperature: −40 to +85 °C

Humidity: Up to 95% RH, non-condensing

Protection Rating: IP00 (requires enclosure for industrial use)

Dimensions & Weight

Dimensions (L × W × H): 195 × 100 × 32 mm

Weight: 1.33 kg
