ABB SDCS-PIN-21 3ADT306200R1 Power Interface Board

Overview

The ABB SDCS-PIN-21 is a power interface board used in ABB’s SDCS (Supervisory Distributed Control System) platforms. It provides reliable power distribution and interfaces between system modules, ensuring stable operation and fault isolation for industrial automation environments.

General Information

Part Number: 3ADT306200R1

Manufacturer: ABB

Brand / Country of Origin: ABB / Switzerland

Type: Power Interface Board

Mounting: Rack or card installation within SDCS chassis

Technology: Power distribution, module interfacing, diagnostic support

Power Specifications

Supply Voltage: DC input as per system requirements

Power Consumption: ≤ 15 W

Input: Powered via SDCS backplane

Protection: Overvoltage and short-circuit protection

Indicators: LEDs for power status and fault detection

Communication & Interface

Interface Ports: Connects system modules for power and signaling

Diagnostics: Fault detection, status reporting, and link monitoring

Operator Interface: LED indicators for power and fault

Reset Features: Supports soft and hardware reset

Environmental

Operating Temperature: 0 to +55 °C

Storage Temperature: −20 to +70 °C

Humidity: 5% to 95% RH, non-condensing

Protection Rating: Standard industrial cabinet environment

Dimensions & Weight

Dimensions (L × W × H): 265 × 282 × 40 mm

Weight: 0.6 kg
