ABB 1MRK002133-ACr01 Analog-Digital Module

Overview

The ABB 1MRK002133-ACr01 Analog-Digital Module is an industrial automation component designed for precise analog and digital signal processing. It converts, monitors, and controls signals within protection and control systems, ensuring accurate data acquisition and reliable operation in critical industrial environments.

General Information

Part Number: 1MRK002133-ACr01

Manufacturer: ABB

Brand: ABB

Country of Origin: Switzerland/Sweden

Series: Protection & Control I/O Systems

Type: Analog-Digital Module

Function: Analog and digital signal conversion and processing

Application: Substation automation, industrial protection, and monitoring systems

Compatibility: ABB protection and control platforms

Installation: Panel or rack mounted module integration

Power Specifications

Supply Voltage: 24 V DC

Power Consumption: Low power industrial operation

Input Protection: Surge and electrical isolation protection

Output Protection: Short-circuit and overload protection

Status Indicators: LED indication for operational and fault status

Communication & Interface

Input Channels: Analog and digital signal inputs for monitoring and control

Output Channels: Converted and processed analog/digital outputs

Interface Type: System backplane or module-level communication

Signal Processing: Real-time analog-to-digital and digital-to-analog conversion

Diagnostics: Built-in fault detection and signal integrity monitoring

Configuration: Software-configurable via ABB control system tools

Environmental

Operating Temperature: -25°C to +70°C

Storage Temperature: -40°C to +85°C

Relative Humidity: 5% to 95% non-condensing

Shock Resistance: Designed for industrial and substation environments

Vibration Resistance: Suitable for continuous operation in harsh conditions

Protection Rating: Industrial enclosure installation environment

Dimensions & Weight

Dimensions (L × W × H): 220 × 120 × 30 mm

Weight: 0.186 kg

Accurate Signal Conversion – Ready for Industrial Use!
