ABB CPM01 1KHL160038R0102N Control Board

Overview

The ABB CPM01 is a control board designed for industrial automation and drive system applications. It is responsible for managing control logic, coordinating system communication, and ensuring stable operation between input/output modules and power electronics. The board is widely used in ABB drive and control architectures where reliable processing and system stability are required.

General Information

Part Number: 1KHL160038R0102N

Manufacturer: ABB

Brand: ABB

Country of Origin: Sweden

Type: Control Board

Series: CPM01

Function: Control logic processing and system coordination

Application: Industrial automation systems, drive control units, motor control assemblies

Mounting: Panel or chassis installation

Power Specifications

Operating Voltage: System dependent, designed for ABB drive/control platforms

Power Consumption: Low-power electronic control design

Protection: Electrical isolation and system-level fault protection

Indicators: Status LEDs for operation and fault monitoring

Communication & Interface

Interface Type: Internal control and signal interface

Signal Function: Coordination between control logic, I/O modules, and power stages

System Compatibility: ABB industrial drives and automation systems

Diagnostics: System-level monitoring and fault detection via controller

Environmental

Operating Temperature: −25°C to +60°C

Storage Temperature: −40°C to +70°C

Humidity: 5% to 95% RH, non-condensing

Vibration Resistance: Industrial-grade design suitability

Protection Rating: Installed within protected control enclosure

Dimensions & Weight

Dimensions (H × W × D): 250 × 35 × 130 mm

Weight: 0.6 kg

Reliable Performance • Industrial Grade Design
