Bently Nevada 3500/54 286566-01 + 133396-01 | Proximity Probe Interface Module Original

Overview
The Bently Nevada 3500/54 (286566-01 + 133396-01) is a proximity probe interface module used in the 3500 series machinery protection system. It converts signals from eddy-current proximity probes into processed vibration and position data for machinery protection and monitoring.

General Information
Part Number: 286566-01 + 133396-01

Manufacturer: Bently Nevada

Series: 3500

Type: Proximity Probe Interface Module

Mounting: Installed in 3500 series rack or chassis

Brand / Country of Origin: Bently Nevada / United States

Technology: Signal conditioning for proximity probes with relay outputs and diagnostic monitoring

Power Specifications
Supply Voltage: Powered via the 3500 system backplane

Power Consumption: Low, suitable for continuous operation

Input: Accepts signals from eddy-current proximity probes

Protection: EMC-protected and industrial-grade design

Indicators: LED indicators for channel status, alarms, and module health

Communication & Interface
Interface Type: Backplane connector for communication with 3500 system

Module Role: Processes probe signals, reports vibration and shaft position data, triggers alarms

Diagnostics: Monitors signal integrity, probe faults, and channel health

Operator Interface: LED indicators and integration with system HMI

Reset Features: Supports manual or system-controlled reset

Environmental
Operating Temperature: −40 to +70 °C

Humidity: Up to 95% RH, non-condensing

Protection Rating: Suitable for installation in enclosed industrial control cabinets

Dimensions & Weight
Dimensions (L × W × H): Approximately 241 × 24 × 241 mm

Weight: ~0.85 kg

New original components available now, with 24-hour customer assistance.
