Foxboro RH927AH | Input Module Recommended products

Overview
The Foxboro RH927AH is an industrial input module designed for Foxboro I/A Series systems. It provides reliable and isolated analog temperature measurement for RTD or thermocouple sensors, ensuring stable and accurate data transmission to the control processor.

General Information
Part Number: RH927AH
Manufacturer: Foxboro (Schneider Electric)
Series: 900 Series I/O
Type: Temperature Input Module
Mounting: Installs into an I/A Series I/O chassis
Technology: Isolated analog measurement with onboard diagnostics

Power Specifications
Supply Voltage: 24 V DC (from I/O backplane)
Power Consumption: ≤ 8 W
Input Source: System backplane power
Protection: Surge protection, isolation, over-voltage protection
Indicators: LED indicators for module health and status

Communication & Interface
Signal Type: RTD or thermocouple temperature input
Input Channels: 1–2 channels (depending on configuration)
Signal Processing: Linearization and cold-junction compensation
Diagnostics: Sensor failure detection and fault reporting
Configuration: Performed through Foxboro system software
Reset Options: Supports software-initiated reset

I/O & Channels
Input Type: Temperature (TC/RTD)
Number of Channels: 1–2
Output: Digitized measurement sent to controller
Load Support: Not applicable (signal-processing only)

Environmental
Operating Temperature: −20 to +70 °C
Humidity: Up to 95% RH, non-condensing
Protection Rating: Suitable for protected industrial cabinet environments

Dimensions & Weight
Dimensions (L × W × H): 130 × 32 × 120 mm
Weight: ~ 0.25 kg

Each unit is factory original, brand new, and available immediately — contact us for your quote now.
