GE IS200TRPGH1BDD Main Trip Terminal Block

Overview
The GE IS200TRPGH1BDD is a main trip terminal block designed for GE Mark VI control systems. It is used to manage critical trip circuit connections, providing secure and reliable signal termination for turbine protection and shutdown functions in industrial automation environments.

General Information
Part Number: IS200TRPGH1BDD

Manufacturer: General Electric (GE)

Brand: GE

Country of Origin: USA

Series: Mark VI Control System

Type: Main Trip Terminal Block

Function: Trip circuit signal termination and protection interface

Installation: Panel-mounted terminal assembly

Application: Gas turbine protection systems, steam turbine control, industrial safety shutdown

Power Specifications
Supply Voltage: System-dependent (Mark VI protection architecture)

Power Consumption: Passive module (no active power consumption)

Output Interface: Trip signal relay/contact termination

Protection: High-reliability isolation for safety-critical circuits

Signal Handling: Designed for emergency shutdown and protection signaling

Communication & Interface
System Interface: GE Mark VI turbine control system integration

Signal Type: Trip and protection circuit signal termination

Wiring Interface: Screw-terminal field connections

Diagnostics: System-level monitoring via Mark VI controller

Compatibility: Designed for safety-critical turbine protection loops

Environmental
Operating Temperature: Industrial control cabinet environment (0 to +55 °C typical)

Storage Temperature: −40 to +85 °C

Humidity: 5% to 95% non-condensing

Vibration Resistance: Turbine-grade industrial durability

Protection Rating: Enclosed panel installation

Dimensions & Weight
Dimensions (L × W × H): 330.2 × 20 × 178 mm

Weight: 0.907 kg

Critical Protection Interface for Reliable Shutdown Control Systems
