GE IS220PAOCH1BE Analog Input/Output Module

Overview

The GE IS220PAOCH1BE is an analog input/output module designed for industrial automation and turbine control systems. It provides reliable analog signal acquisition and output control, enabling precise monitoring and regulation of field devices in real-time process environments.

General Information

Part Number: IS220PAOCH1BE
Manufacturer: GE (General Electric)
System Series: Mark VIe
Brand: GE
Country of Origin: USA
Type: Analog Input/Output Module
Function: Combined analog signal input and output processing
Installation: Rack-mounted control system module
Compatibility: GE Mark VIe distributed control system
Technology: High-resolution A/D and D/A conversion with integrated diagnostics

Power Specifications

Supply Voltage: 28 V DC (system dependent)
Power Consumption: Typically ≤ 12 W
Input Power Source: System backplane or external DC supply
Protection: Over-voltage, over-current, and reverse polarity protection
Status Indication: LED indicators for power, channel status, and fault

Communication & Interface

Signal Interface: Analog input and output channels
Input Types: 4–20 mA / voltage signals (configurable)
Output Types: 4–20 mA analog outputs
Data Transfer: High-speed backplane communication with controller
Channel Isolation: Galvanic isolation per channel
Diagnostics: Loop monitoring, fault detection, signal validation
System Integration: Fully integrated with GE Mark VIe architecture

Environmental

Operating Temperature: 0 to +65 °C
Storage Temperature: −40 to +85 °C
Humidity: 5%–95% RH, non-condensing
Vibration Resistance: Industrial turbine control standard
Protection Class: IP20

Dimensions & Weight

Dimensions (L × W × H): 178 × 120 × 50 mm
Weight: 1.2 kg
