Overview
The HIMA F3240 is a safety-rated discrete output module designed for HIMA HIMax and HIQuad safety instrumented systems (SIS). It provides reliable, isolated digital outputs to drive actuators, relays, and other field devices in critical safety applications, ensuring fast and secure response in emergency shutdown and process safety systems.
General Information
Part Number: F3240
Manufacturer: HIMA
Series: HIMax / HIQuad Compatible
Type: Discrete Output Safety Module
Mounting: Installed on HIMA rack or baseplate system
Technology: Safety-certified digital output with channel isolation and diagnostic monitoring
Power Specifications
Supply Voltage: 24 V DC (via system backplane)
Power Consumption: ≤ 8 W
Power Source: Redundant backplane supply supported
Protection: Short-circuit protection, surge suppression, channel isolation
Indicators: LEDs for channel status, module health, and fault detection
Communication & Interface
Output Type: Discrete digital output
Channel Isolation: Independent isolation for each output channel
Output Function: Drives actuators, relays, or other field devices
Diagnostics: Output monitoring, fault detection, self-test capabilities
Configuration: Managed through HIMA configuration and engineering tools
Reset Options: Supports software reset via system controller
I/O & Channels
Channel Count: 16 isolated outputs (typical configuration)
Output Function: Logic-level control of field devices for safety-critical applications
External Load Support: Supports standard industrial relay and actuator loads
Environmental
Operating Temperature: −20 to +60 °C
Humidity: Up to 95% RH, non-condensing
Protection Rating: Suitable for installation in standard control cabinets
Dimensions & Weight
Dimensions (L × W × H): Approx. 160 × 20 × 125 mm
Weight: ~ 0.25 kg
