Honeywell FS‑SAI‑1620M | Analog Input Module Rave reviews

Overview
The Honeywell FS‑SAI‑1620M is a high‑density analog input module engineered for industrial safety instrumented systems. With 16 channels, the module supports acquisition of analog signals from field sensors and provides robust diagnostics and redundancy for safety‑critical applications.

General Information
Brand: Honeywell
Country of Origin: United States
Model Number: FS‑SAI‑1620M
Series: Safety Manager I/O Modules
Product Type: Analog Input Module (Safety‑rated)
Application: Safety instrumented systems, process automation, analog signal acquisition

Power Specifications
Supply Voltage: 24 V DC (nominal)
Current Consumption: Approx. 35 mA typical (module alone)
Protection: Internal surge and short‑circuit protections, designed for safe system environments

Communication & Interface
Channels: 16 analog input channels
Supported Signal Types: 0–20 mA and/or 4–20 mA (depending on variant)
Input Range: Up to 4.1 V when paired with appropriate FTA module (field termination assembly)
Input Resistance: High impedance (for voltage input modes)
Diagnostics: Channel fault monitoring, system‑level diagnostics, supports SIL‑rated applications

Environmental
Operating Temperature: –40 °C to +70 °C
Storage Temperature: –55 °C to +85 °C
Humidity: Up to 95% RH, non‑condensing
Installation: Suitable for control cabinet installation; designed for safe, high‑reliability industrial environments

Dimensions & Weight
Dimensions: 20 × 190 × 128 mm
Weight: Approx. 3 kg
