Overview
The Honeywell TC-PPDO11 is a digital output module used in Honeywell’s TDC 3000 and Experion process control systems. It provides reliable relay-based output channels to control field devices such as actuators, valves, and indicators in industrial automation applications.
General Information
Part Number: TC-PPDO11
Manufacturer: Honeywell
Brand / Country of Origin: Honeywell / United States
Series: TC Series
Type: Digital Output Module
Mounting: Standard panel or rack installation
Technology: Electromechanical relay outputs with LED indication and channel isolation
Power Specifications
Supply Voltage: 24 V DC
Output Rating: Up to 240 VAC or 125 VDC, 2 A per channel
Power Consumption: Low, driven via relay coil
Protection: Channel isolation and surge protection
Indicators: LED status indicators for all channels
Communication & Interface
Output Type: Isolated relay contacts
Channels: 8 or 16 configurable output channels
Connection Type: Screw terminals for field wiring
Diagnostics: LED indicators for status and fault monitoring
System Integration: Compatible with Honeywell DCS I/O racks
Environmental
Operating Temperature: −10 to +60 °C
Humidity: 5–95% RH, non-condensing
Storage Temperature: −40 to +85 °C
Installation Environment: Indoor industrial control cabinets
Dimensions & Weight
Dimensions (W × H × D): 307 × 257 × 50 mm
Weight: ~ 2.0 kg
