Honeywell 8C-SDOX01 51307051-175 Digital Output Module 12-Month Warranty

Overview

The Honeywell 8C-SDOX01 (Part No. 51307051-175) is a relay extension module for the Series 8 I/O system. It provides isolated dry-contact outputs (Form-C) to control higher voltage or current loads while keeping the digital I/O module signals isolated from field wiring.

General Information

• Part Number: 51307051-175 / 8C-SDOX01

• Product Name / Model: 8C-SDOX01 Relay Extension Module

• Manufacturer: Honeywell

• Country of Origin: United States

• Series / Module Type: Series 8 Digital Output Relay Extension

• Type: Relay Extension / Digital Output Module

• Mounting / Format: 15″ IOTA compatible module

• Application Area: Control systems, DCS, field relay outputs

Electrical Specifications

• Number of Output Channels: 32 (Form-C SPDT contacts)

• Contact Rating (Resistive): 5 A @ 125/250 VAC; 3 A @ 30 VDC

• Contact Rating (Inductive): 2 A @ 125/250 VAC (PF 0.4)

• Isolation (Channel to Logic Common): 1,500 VAC RMS

• Turn-On Time / Turn-Off Time: Max 20 ms each

• Minimum Load: 10 mA at 5 V DC

• Inrush Capability: Up to 10 A for 4 s at 10% duty

• Output Link: Three terminals per channel (NO, NC, COM)

• LED Indication: Each channel has indicating LED

Environmental

• Operating Temperature: –40 °C to +70 °C

• Storage Temperature: –40 °C to +85 °C

• Relative Humidity: 5% to 95%, non-condensing

• Atmospheric Protection: Conformal coated for moisture, dust, and chemical resistance

• Certification / Hazardous Area Rating: Zone 2, Ex ec nC IIC T4 Gc (relay extension board only)

Dimensions & Weight

• Dimensions (L × W × H):  31.8 × 63.5 × 12.7 mm

• Weight:  0.113 kg

Genuine new inventory, ready to ship anytime.
