Honeywell 8C-TDIL01 51306856-175 Digital Input Module Quality Assurance

Overview
The Honeywell 8C-TDIL01 (Part No. 51306856-175) is a 32-channel digital input module designed for Honeywell Experion C300 and Series 8 systems. It supports TTL input signals, providing high-speed and precise data acquisition for process control and industrial automation applications. The module ensures reliable performance and efficient input signal management.

General Information

• Part Number: 51306856-175 / 8C-TDIL01

• Product Name / Model: 8C-TDIL01 Digital Input Module

• Manufacturer: Honeywell

• Country of Origin: United States

• Series / Module Type: Series 8 / Experion C300 I/O

• Type: Digital Input Module (non-redundant)

• Mounting / Format: Backplane / DIN rail module (IOTA form factor)

• Application Area: Process control, industrial automation, machine monitoring, emergency shutdown systems

Electrical Specifications

• Number of Input Channels: 32

• Input Signal Type: TTL (Transistor-Transistor Logic)

• Operating Voltage: 24 V DC

• Scan Cycle / Response Time: Standard mode: 20 ms; Fast mode: 5 ms

• Event Sequence Resolution: 1 ms

• Diagnostics: Channel fault detection, input status monitoring

• Redundancy: Non-redundant

Environmental

• Operating Temperature: 0 °C to +60 °C

• Storage Temperature: −40 °C to +70 °C

• Relative Humidity: Up to 95%, non-condensing

• Cooling: Natural convection

• Protection / Coating: Optional conformal coating for moisture, dust, and corrosion resistance

Dimensions & Weight

• Dimensions (L × W × H): 105 × 72 × 120 mm

• Weight: Approximately 0.56 kg

Factory-original new stock, ready for quick dispatch and response.
