Honeywell CC-GAIC21 Analog Input/Output Module Price Advantage

Overview
The Honeywell CC-GAIC21 is an analog I/O module designed for hazardous area (GI/IS) use within the Series C I/O architecture (used with the C300 controller). It offers galvanically isolated analog inputs/outputs suitable for demanding industrial process control, particularly in explosion-risk environments.

General Information

• Manufacturer: Honeywell Process Solutions

• Origin: United States

• Model Number: CC-GAIC21

• Type: Analog Input/Output Module (GI/IS rated)

• Series: Series C I/O – Experion PKS platform

• Function: Provides isolated analog signal interface (input or input/output) for process instrumentation in hazardous locations

Power Specifications

• Supply Voltage: Nominal 24 V DC (series typical)

• Input/Output Isolation: Up to ~1500 V AC RMS field to logic common (based on Series C analog module specs)

• Power Consumption: Typical low power; fully loaded module <10 W

Communication & Interface

• System Interface: Mounted on IOTA (Input/Output Termination Assembly); plugs into IOM (Input/Output Module) slot of Series C rack; communicates over I/O Link or equivalent bus within the C300 system.

• Channel Features: Analog channels (for example: 4–20 mA, 0–10 V) in hazardous-area rated module; open-wire detection and diagnostics may be available.

• Field Connections: Suitable for field wiring in Zone/Division explosion-hazard rated environments (GI/IS rated) with galvanic isolation and protective separation.

Environmental

• Operating Temperature: –40 °C to +70 °C (typical for Series C modules)

• Humidity: 5 % to 95 % RH, non-condensing

• Protection Rating: IP20 (when installed in cabinet); module is designed for use within protective enclosure in hazardous area classification.

Dimensions & Weight

• Dimensions (L × W × H): Approx. 313 × 278 × 30 mm

• Weight: Approx. 0.55 kg

Brand-new originals in stock, customer service 24/7, transparent pricing and rapid quotes.
