Honeywell RM7800M1011 Programmable Burner Control

Overview

The RM7800M1011 is a programmable burner control unit designed for Honeywell industrial automation systems. It provides advanced control of burner operations, including ignition, flame monitoring, and safety interlocks, allowing flexible, safe, and efficient combustion management in industrial heating and process applications.

General Information

Part Number: RM7800M1011

Manufacturer: Honeywell / USA

Series: RM7800

Module Type: Programmable Burner Control

Mounting: Panel or DIN rail installation within Honeywell control systems

Technology: Microprocessor-based control with integrated fail-safe relays and LED diagnostics

Power Specifications

Supply Voltage: 24 V DC

Power Consumption: 5 W typical

Output Protection: Overload and short-circuit protection for relay outputs

Indicators: LED indicators for operational status, faults, and safety conditions

Communication & Interface

Communication Ports: System bus interface for integration with Honeywell controllers

I/O Channels: Digital and relay outputs for burner control

Input Type: Flame sensors, limit switches, and other safety devices

Diagnostics: LED monitoring for input/output activity and module health

Operator Interface: Visual feedback for operational and fault status

Reset Features: Supports controller- or system-initiated reset

Environmental

Operating Temperature: 0 to 55 °C

Storage Temperature: −20 to +85 °C

Humidity: 5% to 95% RH, non-condensing

Vibration Resistance: Complies with industrial standards

Protection Rating: IP20, suitable for enclosed industrial cabinets

Dimensions & Weight

Dimensions (L × W × H): 127 × 127 × 133 mm

Weight: 0.83 kg
